S355J0H EN 10219 Square Hollow Section
Cold Formed EN 10219 S355JOH Square Hollow Section
Cold Formed EN 10219 S355JOH Square Hollow Section Manufacturer & Supplier in Mumbai, India.
EN 10219 Cold Formed S355J0H ERW SHS Pipes Dealers, EN 10219 Cold Formed S355J0H ERW SHS Pipes Exporter, Cold Formed EN 10219 S355J0H SHS Pipe, EN 10219 S355J0H Seamless Cold Formed Square Hollow Section Tubing, Carbon Steel S355J0H Square Hollow Section Suppliers, Grade S355J0H Cold Formed Welded Structural Square Hollow Section, EN 10219 S355J0H MS Cold Formed Square Tube Stockists in Mumbai, India.
Ranfit Metal is a well-known manufacturer, supplier, and stockiest of Cold Formed EN 10219 S355JOH Square Hollow Section. The S355JOH Cold-Formed Welded Structural Square Hollow Section (SHS) is a versatile and widely used steel section in construction and engineering applications.
The BS EN 10219 S355JOH Square Hollow Section is available in different diameter from 1inch to 26inch and the wall thickness of it such as SCH 80, SCHY 30, SCH 40, SCH 20, SCH 10, SCH 60 and else. Cold Formed EN 10219 S355J0H Square Hollow Section Pipes are primarily utilized at extremely high temperatures and exhibit excellent corrosion resistance in high-temperature environments. Additionally, it has a high level of resistance to general corrosion. Ideal for reducing material costs without compromising strength. S355JOH Seamless Square Hollow Section is adaptable for multiple applications due to square geometry.
The tensile and yield strengths of these cold-formed EN 10219 S355J0H square box sections are very high. It is produced in accordance with global quality standards. When it comes to oxidation corrosion, these EN 10219 S55J0H mild steel cold formed square tubes are the most resistant. The EN 10219 S355JOH square hollow section (SHS) is a cold-formed structural steel product commonly used in construction and engineering projects. Produced by forming flat steel sheets into a square or rectangular shape and then welding along the seam.
S355J0H CS Cold Formed Square Pipes Distributors, BS EN 10219 S355J0H Cold Formed SHS Tubes, Cold Formed EN 10219 S355J0H Square Box Sections, Cold Formed S355J0H Mild Steel Square Hollow Section Exporters, EN 10219 S355J0H Seamless Cold Formed Square Hollow Section Tubing, Grade S355J0H Cold Formed Welded Structural Square Hollow Section Exporter in India.
Key Standards
EN 10219: Cold-formed welded structural hollow sections of non-alloy and fine grain steels.
S355: Indicates a minimum yield strength of 355 MPa.
J: Refers to impact toughness, suitable for low-temperature environments (-20°C).
OH: Refers to Structural Hollow Sections.
Cold Formed EN 10219 S355J0H Square Hollow Section Specifications
| Standard No | BS EN 10219 - Cold Formed Welded Structural Hollow Sections of Non-alloy and Fine Grain Steels |
| Grade | S355J0H |
| SHS (Square Hollow Sections) Sizes | 20*20mm-400*400mm |
| Outside Diameter | 21.3—457.2mm |
| Wall Thickness | 1.8—-14.27mm |
| Length | 6000 – 12 000/18 000 mm |
| Straightness | Min 1 = 200 of any lengths measured along the centre line unless otherwise specifically managed |
| Tolerance | max 2 ± 0.05 mm |
| End Finish | mill-cut finish without further machining, Plain ended-Mechanically sheared |
| Surface Finish | Black without any surface treatment of oiling /varnishing. |
| Weldability | Square Hollow Sections are weldable with standard M.S. Electrodes without any pre-heating. |
EN 10219 S355J0H Square Hollow Pipes and Tubing Material Equivalent
| Steel grade | Maximum CEV for nominal thicknesses ≤40mm |
|
| Steel name | Steel number | |
| S355J0H | 1.0547 | 0,45 |
EN 10219 S355J0H Square Hollow Section Chemical Properties
| Material | Type of de-oxidation a | % by mass, maximum |
||||||
|---|---|---|---|---|---|---|---|---|
| Grade | DIN | C | Si | Mn | P | S | N b | |
| S355J0H | 1.0547 | FF | 0,22 | 0,55 | 1,60 | 0,035 | 0,035 | 0,009 |
EN 10219 S355J0H Square Hollow Pipes & Tubes Mechanical Strength
| Steel Material | Min Yield Strength ReH MPa |
Tensile Strength Rm MPa |
Min Elongation A d % |
Min Impact energy KV e J |
|||||
|---|---|---|---|---|---|---|---|---|---|
| Specified Thickness mm | Specified Thickness mm |
Specified Thickness mm |
at Test temperature of |
||||||
| Grade | DIN | ≤ 16 |
> 16 ≤ 40 |
< 3 |
≥ 3 ≤ 40 | ≤ 40 | -20°C | 0°C | 20°C |
| S355J0H a | 1.0547 | 355 | 345 | 510-680 | 470-630 | 20 c | - | 27 | - |
Types of EN 10219 S355J0H Hollow Section Square
S355J0H EN 10219 Square Hollow Pipes
EN 10219 S355J0H Square Hollow Tubing
S355J0H Structural Square Hollow Sections
EN 10219 S355J0H Welded Square Hollow Pipes
cold formed S355J0H SHS Tube
Cold Formed EN 10219 S355J0H Square Hollow Section Size Chart
| Size mm | kg/m | Size mm | kg/m |
|---|---|---|---|
| 20 x 20 x 2.0 | 1.12 | 20 x 20 x 2.5 | 1.35 |
| 25 x 25 x 1.5 | 1.06 | 25 x 25 x 2.0 | 1.43 |
| 25 X 25 X 2.5 | 1.74 | 25 X 25 X 3.0 | 2.04 |
| 30 X 30 X 2.0 | 1.68 | 30 X 30 X 2.5 | 2.14 |
| 30 X 30 X 3.0 | 2.51 | 40 x 40 x 1.5 | 1.81 |
| 40 x 40 x 2.0 | 2.31 | 40 x 40 x 2.5 | 2.92 |
| 40 x 40 x 3.0 | 3.45 | 40 x 40 x 4.0 | 4.46 |
| 40 x 40 x 5.0 | 5.40 | 50 x 50 x 1.5 | 2.28 |
| 50 x 50 x 2.0 | 2.93 | 50 x 50 x 2.5 | 3.71 |
| 50 x 50 x 3.0 | 4.39 | 50 x 50 x 4.0 | 5.72 |
| 50 x 50 x 5.0 | 6.97 | 60 x 60 x 3.0 | 5.34 |
| 60 x 60 x 4.0 | 6.97 | 60 x 60 x 5.0 | 8.54 |
| 60 x 60 x 6.0 | 9.45 | 70 x 70 x 3.0 | 6.28 |
| 70 x 70 x 3.6 | 7.46 | 70 x 70 x 5.0 | 10.11 |
| 70 x 70 x 6.3 | 12.50 | 70 x 70 x 8 | 15.30 |
| 75 x 75 x 3.0 | 7.07 | 80 x 80 x 3.0 | 7.22 |
| 80 x 80 x 3.6 | 8.59 | 80 x 80 x 5.0 | 11.70 |
| 80 x 80 x 6.0 | 13.90 | 90 x 90 x 3.0 | 8.01 |
| 90 x 90 x 3.6 | 9.72 | 90 x 90 x 5.0 | 13.30 |
| 90 x 90 x 6.0 | 15.76 | 90 x 90 x 8.0 | 20.40 |
| 100 x 100 x 3.0 | 8.96 | 100 x 100 x 4.0 | 12.00 |
| 100 x 100 x 5.0 | 14.80 | 100 x 100 x 5.0 | 14.80 |
| 100 x 100 x 6.0 | 16.19 | 100 x 100 x 8.0 | 22.90 |
| 100 x 100 x 10 | 27.90 | 120 x 120 x 5 | 18.00 |
| 120 x 120 x 6.0 | 21.30 | 120 X 120 X 6.3 | 22.30 |
| 120 x 120 x 8.0 | 27.90 | 120 x 120 x 10 | 34.20 |
| 120 X 120 X 12 | 35.8 | 120 X 120 X 12.5 | 41.60 |
| 140 X 140 X 5.0 | 21.10 | 140 X 140 X 6.3 | 26.30 |
| 140 X 140 X 8 | 32.90 | 140 X 140 X 10 | 40.40 |
| 140 X 140 X 12.5 | 49.50 | 150 X 150 X 5.0 | 22.70 |
| 150 X 150 X 6.3 | 28.30 | 150 X 150 X 8.0 | 35.40 |
| 150 X 150 X 10 | 43.60 | 150 X 150 X 12.5 | 53.40 |
| 150 X 150 X 16 | 66.40 | 150 X 150 X 16 | 66.40 |
| 180 X 180 X 5 | 27.40 | 180 X 180 X 6.3 | 34.20 |
| 180 X 180 X 8 | 43.00 | 180 X 180 X 10 | 53.00 |
| 180 X 180 X 12.5 | 65.20 | 180 X 180 X 16 | 81.40 |
| 200 X 200 X 5 | 30.50 | 200 X 200 X 6 | 35.8 |
| 200 x 200 x 6.3 | 38.2 | 200 x 200 x 8 | 48.00 |
| 200 x 200 x 10 | 59.30 | 200 x 200 x 12.5 | 73.00 |
| 200 x 200 x 16 | 91.50 | 250 x 250 x 6.3 | 48.10 |
| 250 x 250 x 8 | 60.50 | 250 x 250 x 10 | 75.00 |
| 250 x 250 x 12.5 | 92.60 | 250 x 250 x 16 | 117.00 |
| 300 x 300 x 6.3 | 57.90 | 300 x 300 x 8 | 73.10 |
| 300 x 300 x 10 | 57.90 | 300 x 300 x 8 | 90.70 |
| 300 x 300 x 12.5 | 112.00 | 300 x 300 x 16 | 142.00 |
| 350 x 350 x 8 | 85.70 | 350 x 350 x 10 | 106.00 |
| 350 x 350 x 12.5 | 132.00 | 350 x 350 x 16 | 167.00 |
| 400 x 400 x 10 | 122.00 | 400 x 400 x 12 | 141.00 |
| 400 x 400 x 12.5mm | 152.00 | 400 x 400 x 16 | 192 |
EN 10219 S355JOH SHS Dimensional Tolerances
| Characteristic | Square Hollow Sections |
| Outside Dimension | ± 1% with a min of ± 0.5mm |
| Thickness (T) | T≤5mm: ±10% |
| T>5mm: ± 0.5mm | |
| Out-of-Roundness | – |
| Convexity | Max .8% with min 0.5mm |
| Squareness of side | 90° ± 1° |
| External Corner Profile | T≤6mm: 1.6T to 2.4T |
| 6<T≤10mm: 2.0T to 3.0T | |
| T,10: 2.4T to 3.6T | |
| Twist | 2mm plus 0.5mm/m |
| Straightness | 0.15% of total |
| Mass | ±6% on individual length |
Buy High Quality Cold Formed EN 10219 S355JOH Square Hollow Section
Request the latest EN 10219 S355JOH SHS Price List.
Please call us : +91 9987673092
mail us : sales@ranfitmetal.com
to request the updated price list and ready stock information along with your requirement.
EN 10219 S355JOH SHS Available Types
| S355JOH Cold Formed Square Hollow Section Supplier in Mumbai | S355JOH Welded Square Tubing, |
| S355JOH Cold Formed Square Box Sections | S355JOH Seamless Square Hollow Section Stockist |
| Cold Formed BS EN 10219 S355JOH CS Hollow Square Tube, | Welded Cold Formed EN 10219 S355JOH SHS Pipe |
| S355JOH Cold Formed SHS Tube Stokist | EN 10219 S355JOH Structural Steel Piping |
| High Temperature 10219 S355JOH Pipes | EN 10219 S355JOH MS Square Hollow Section Pipe |
| S355JOH Cold Rolled Square Hollow Sections Supplier | EN 10219 S355JOH Cold Formed SHS Manufacturer |
| EN 10219 S355JOH Cold Formed Seamless Pipe | EN 10219 S355JOH Cold Formed ERW Pipes |
| EN 10219 S355JOH Carbon Steel Welded SHS | EN 10219 Cold Formed S355JOH MS SHS Tube |
| S355JOH Seamless Cold Formed SHS Tubes | S355JOH Cold Formed Square Hollow Structural Sections |
| Schedule 40 S355JOH Seamless Pipes | Cold formed EN 10219 S355JOH structural hollow sections (CFSHS) |
Cold Formed S355JOH SHS Manufacturing Process
EN 10219 S355JOH Cold Formed Square Hollow Sections – Application Industrty
- Petrochemical Industry
- Aerospace Industry
- Refineries
- Construcion
- Chemical Industry
- Railway Industry
- Oil & Gas Industry
- Ship Building
