Cold Formed EN 10219 S275J2H Rectangular Hollow Section

S275J2H Rectangular Hollow Section

Cold Formed EN 10219 S275J2H Rectangular Hollow Section Manufacturer, SS S275J2H Hollow Section Supplier in Mumbai, India.


Cold Formed S275J2H Seamless Rectangular Hollow Section, S275J2H Cold Formed EN 10219RHS, Cold Formed S275J2H CF RHS, S275J2H ERW RHS Tubing, S275J2H Cold Formed Rectangular Pipe, S275J2H Cold Formed Rectangular Tube, Cold Formed S275J2H RHS Seamless Pipes, Cold Formed S275J2H CS RHS Tube, S275J2H CS Cold Formed Rectangular Hollow Section EN 10219 Stockist in Mumbai, India.


Ranfit Metal is a well-known manufacturer, supplier, and stockiest of Cold Formed EN 10219 S275J2H Rectangular Hollow Section. The EN 10219 S275J2H is a specification for a specific grade of cold-formed structural sections formed from steel strips or plates, followed by welding their edges.

With surface treatments such as galvanizing or coating, Cold Formed EN 10219 S275J2H RHS Welded Pipes exhibit strong corrosion resistance, prolonging the lifespan of structures. They possess excellent processing capabilities, allowing for straightforward cutting, welding, and other fabrication processes. Complying with the EN 10219 standard, it features a grade of S275J2H, which indicates a minimum yield strength of 275 MPa and guarantees good toughness at low temperatures. This type of section is widely used in construction and engineering applications due to its strength, lightweight nature, and versatility, making it suitable for various structural applications, including building frames, bridges, and industrial structures.

EN 10219 S275J2H Seamless Rectangular Hollow Section has advantage of High strength-to-weight ratio, Excellent resistance to impact and fatigue, Uniform wall thickness and dimensional accuracy. In civil engineering, S275J2H Rectangular Hollow Sections are extensively used as beams, columns, and trusses, contributing to the resilience and stability of structures.


EN 10219 S275J2H MS Cold Formed Rectangular Tube Stockists, BS EN 10219 S275J2H Cold Formed RHS Tubes, Carbon Steel S275J2H Rectangular Hollow Section Suppliers in Mumbai, Cold Formed EN 10219 S275J2H Rectangular Box Sections, Cold Formed S275J2H Mild Steel Rectangular Hollow Section Exporters, Cold Formed EN 10219 S275J2H RHS Pipe Supplier, S275J2H CS Cold Formed Rectangular Pipes Distributors in India.


Key Standards

EN 10219: This standard specifies the technical delivery conditions for cold-formed welded structural hollow sections of non-alloy and fine-grain structural steels.

S275: Refers to a minimum yield strength of 275 MPa.

JOH: J- Charpy V-notch impact test at -20°C. H- Hollow section.


Cold Formed EN 10219 S275J2H Rectangular Hollow Section Specifications

Standard No BS EN 10219 - Cold Formed Welded Structural Hollow Sections of Non-alloy and Fine Grain Steels
Grade S275J2H
RHS (Rectangular Hollow Sections) Sizes 10mm x 15mm / 150mmx50mm / 300mmx400mm / 600mmx550mm
Outside Diameter 21.3—457.2mm
Wall Thickness 0.5mm - 25mm
Length 6000-14000 mm
Straightness Minimum 1 : 200th of any length measured along the centre line (mill straightened condition) unless otherwise specifically arranged.
Tolerance Thickness (All sizes +/- 10%)
Surface Protection Black (Self Coloured uncoated), Varnish/Oil Coating, Pre-Galvanized, Hot Dip Galvanized
Packing In bundles, Anticorrosion heat preservation, Varnish coating, Ends can be bevelled or rectangular cut, End Capped Certification & supplementary test, Finishing & Identity Mark

EN 10219 S275J2H Rectangular Hollow Pipes and Tubing Material Equivalent

Steel grade Maximum CEV for
nominal thicknesses ≤40mm
Steel name  Steel number
S275J2H 1.0149 0,40

EN 10219 S275J2H Rectangular Hollow Section Chemical Composition

Grade Min. Yield Strength Reh(Mpa) Tensile Strength Rm (MPa) Elongation % Min. Min. Impact Energy(J)
Thk≤ 16 mm Thk>16 ≤ 40 mm Thk<3 mm Thk≥3 mm -20°C 0°C 20°C
S275J0H 275 265 430-580 410-560 20 - 27 -

EN 10219 S275J2H Rectangular Hollow Pipes & Tubes Mechanical Strength

Grade Min. Yield Strength Reh(Mpa) Tensile Strength Rm (MPa) Elongation % Min. Min. Impact Energy(J)
Thk≤ 16 mm Thk>16 ≤ 40 mm Thk<3 mm Thk≥3 mm -20°C 0°C 20°C
S275J0H 275 265 430-580 410-560 20 - 27 -

Types of EN 10219 S275J2H Hollow Section Rectangular

S275J2H EN 10219 Rectangular Hollow Section

S275J2H EN 10219 Rectangular Hollow Pipes

EN 10219 S275J2H Rectangular Hollow Tubing

S275J2H Structural Rectangular Hollow Sections

EN 10219 S275J2H Welded Rectangular Hollow Pipes

cold formed S275J2H Rectangular SHS Tube

Cold Formed EN 10219 S275J2H Rectangular Hollow Section Size Chart

Size mm kg/m Size mm kg/m
40 x 20 x 2.0 1.68 40 x 20 x 2.5 2.03
40 x 20 x 3.0 2.36 40 x 25 x 1.5 1.44
40 x 25 x 2.0 1.89 40 x 25 x 2.5 2.23
50 x 25 x 2.0 2.21 50 x 25 x 2.5 2.72
50 x 25 x 3.0 3.22 50 x 30 x 2.5 2.92
50 x 30 x 3.0 3.45 50 x 30 x 4.0 4.46
50 x 40 x 3.0 3.77 60 x 40 x 2.0 2.93
60 x 40 x 2.5 3.71 60 x 40 x 3.0 4.39
60 x 40 x 4.0 5.72 70 x 50 x 2 3.56
70 x 50 x 2.5 4.39 70 x 50 x 3.0 5.19
70 x 50 x 4.0 6.71 80 x 40 x 2.5 4.26
80 x 40 x 3.0 5.34 80 x 40 x 4.0 6.97
80 x 40 x 5.0 8.54 80 x 50 x 3.0 5.66
80 x 50 x 4.0 7.34 90 x 50 x 3.0 6.28
90 x 50 x 3.6 7.46 90 x 50 x 5.0 10.11
100 x 50 x 2.5 5.63 100 x 50 x 3.0 6.75
100 x 50 x 4.0 8.86 100 x 50 x 5.0 10.90
100 x 60 x 3.0 7.22 100 x 60 x 3.6 8.59
100 x 60 x 5.0 11.70 120 x 80 x 2.5 7.65
120 x 80 x 3.0 9.03 120 x 80 x 4.0 12.00
120 x 80 x 5.0 14.80 120 x 80 x 6.0 17.60
120 x 80 x 8.0 22.9 150 x 100 x 5.0 18.70
150 x 100 x 6.0 22.30 150 x 100 x 8.0 29.10
150 x 100 x 10.0 35.70 160 x 80 x 5.0 18.00
160 x 80 x 6.0 21.30 160 x 80 x 8.0 27.90
200 x 100 x 5.0 22.70 200 x 100 x 6.0 27.00
200 x 100 x 8.0 35.4 200 x 100 x 10.0 43.60
250 x 150 x 5.0 30.5 250 x 150 x 6.0 38.2
250 x 150 x 8.0 48.0 250 x 150 x 10 59.3
300 x 200 x 6.0 48.10 300 x 200 x 8.0 60.50
300 x 200 x 10.0 75.00 400 x 200 x 8.0 73.10
400 x 200 x 10.0 90.70 400 x 200 x 16 142.00

RHS Thickness Sec Area Unit Moment of Inertia Radius of Gyration Elastic Modulus Torsional Constants Outer
Surface Area
mm mm cm2 kg/m cm4 cm4 cm cm cm3 cm3 cm4 cm3 m2
50x25 2 2.74 2.15 8.38 2.81 1.75 1.01 3.35 2.25 6.97 3.79 0.142
2.6 3.46 2.71 10.16 3.36 1.71 0.99 4.06 2.69 8.27 4.53 0.137
3.2 4.13 3.24 11.63 3.8 1.68 0.96 4.35 3.04 9.52 5.12 0.134
4 4.95 3.88 13.13 4.23 1.63 0.92 5.25 3.38 10.86 5.69 0.129
60x40 2.26 4.76 3.73 22.76 12.09 2.19 1.59 7.59 6.05 25.59 9.83 0.187
2.9 5.25 4.12 24.74 13.11 2.17 1.58 8.25 6.56 28.02 10.66 0.185
3.6 6.35 4.98 28.9 15.23 2.13 1.55 9.63 7.62 33.3 12.41 0.181
4.5 7.67 6.02 33.31 17.44 2.08 1.51 11.1 8.72 39.34 14.29 0.177
60x33 2.6 4.7 3.69 25.15 8.43 2.31 1.34 7.62 5.11 20.75 8.71 0.185
2.9 5.19 4.07 27.33 9.12 2.29 1.33 8.28 5.53 22.65 9.43 0.183
3.6 6.28 4.93 31.87 10.52 2.25 1.29 9.66 6.37 26.71 10.9 0.179
4.5 7.58 5.95 36.64 11.93 2.20 1.25 11.1 7.23 31.21 12.43 0.175
80x40 2.6 5.8 4.55 46.58 15.74 2.84 1.65 11.65 7.87 38.5 13.46 0.227
2.9 6.41 5.03 50.87 17.11 2.82 1.63 12.72 8.56 42.23 14.66 0.225
3.2 7.01 5.5 54.94 18.41 2.8 1.62 13.74 9.21 45.83 15.78 0.224
4 8.55 6.71 64.79 21.49 2.75 1.59 16.2 10.74 54.77 18.49 0.219
4.8 10.01 7.85 73.22 24.03 2.71 1.55 18.3 12.02 62.81 20.79 0.215
96x48 3.2 8.54 6.71 98.61 33.28 3.4 1.97 20.54 13.87 82.13 23.82 0.272
4 10.47 8.22 117.54 39.32 3.35 1.94 24.49 16.38 99.11 28.24 0.267
4.8 12.31 9.66 134.35 44.55 3.3 1.9 27.99 18.56 114.8 32.14 0.263
122x61 3.6 12.32 9.67 232.61 78.83 4.34 2.53 38.13 25.85 193.91 44.5 0.347
4.5 15.14 11.88 278.94 93.78 4.29 2.49 45.73 30.75 235.39 53.13 0.343
5.4 17.85 14.01 320.83 107.03 4.24 2.45 52.6 35.09 347.29 60.89 0.338
120x60 3.2 10.85 8.51 199.88 67.95 4.29 2.5 33.31 22.65 165.83 28.95 0.344
3.6 12.11 9.5 220.75 74.77 4.27 2.48 36.79 24.92 184.1 42.91 0.341
4.5 14.87 11.67 264.52 88.88 4.22 2.44 44.09 29.63 223.34 51.19 0.337
145x82 4.8 20.28 15.92 555.16 228.50 5.23 3.36 76.57 55.73 534.27 94.45 0.429
5.4 22.6 17.74 610.85 250.59 5.2 3.33 84.26 61.12 592.7 103.81 0.426

EN 10219 S275J2H RHS Dimensional Tolerances

Dimensions less than 100mm +/- 1.0% with a minimum of +/- 0.5mm
Dimensions 100mm up to 200mm +/- 0.8%
Dimensions over 200mm +/- 0.6%
Wall thickness (excluding weld area) +/-10% for specified thickness of 5mm or below and +/-0.5mm for thickness greater than 5mm
Concavity/Convexity Max. 0.8% with a minimum of 0.5mm
Squareness of sides 90 Degree +/- 1 Degree
Externalcorner radius 6mm thick or below: 1.6 to 2.4 x wall thickness
Straightness 0.15% of total length
Twist 2mm + ( 0.5mm per mtr ) max

Cold Formed EN 10219 S275J2H SHS

Buy High Quality Cold Formed EN 10219 S275J2H Square Rectangular Section

Request the latest EN 10219 S275J2H Rectangular SHS Price List.
Please call us : +91 9987673092
mail us : sales@ranfitmetal.com
to request the updated price list and ready stock information along with your requirement.

EN 10219 S275J2H SHS Available Types

S275J2H Cold Formed CS Rectangular Hollow Section Supplier S275J2H Welded Rectangular Tubing
EN 10219 S275J2H Cold Formed Rectangular Box Sections EN 10219 S275J2H Seamless Rectangular Hollow Section Stockist
Cold Formed BS EN 10219 S275J2H Hollow Rectangular Tube, Welded Cold Formed EN 10219 S275J2H RHS Pipes
EN 10219 S275J2H Cold Formed RHS Tube Stockist EN 10219 S275J2H Rectangular Structural Steel Piping
High Temperature BS EN 10219 S275J2H Pipes EN 10219 S275J2H MS Rectangular Hollow Section Pipe
S275J2H Cold Rolled Rectangular Hollow Sections Supplier EN 10219 S275J2H Cold Formed ERW RHS Manufacturer
EN 10219 S275J2H Cold Formed Rectangular Seamless Pipe EN 10219 S275J2H Rectangular Cold Formed ERW Pipes
EN 10219 S275J2H Carbon Steel Welded RHS MAnufacturer EN 10219 Cold Formed S275J2H MS RHS Tube
EN 10219 S275J2H Seamless Cold Formed RHS Tubes EN 10219 S275J2H Rectangular Hollow Structural Sections
EN 10219 Schedule 40 S275J2H Seamless Pipes Cold formed EN 10219 S275J2H structural CFRHS

Cold Formed S275J2H SHS Manufacturing Process



EN 10219 S275J2H Cold Formed Rectangular Hollow Sections – Application Industrty
