Cold Formed EN 10219 S275JOH Rectangular Hollow Section

S275JOH Rectangular Hollow Section

Cold Formed EN 10219 S275JOH Rectangular Hollow Section Manufacturer & Supplier in Mumbai, India.


Cold Formed EN 10219 S275JOH Seamless Rectangular Hollow Section, S275JOH Cold Formed RHS, Cold Formed EN 10219 S275JOH ERW RHS Tubing, S275JOH Cold Formed Rectangular Pipe, S275JOH Cold Formed Rectangular Tube, S275JOH CF RHS, Cold Formed S275JOH RHS Seamless Pipes, Cold Formed S275JOH CS RHS Tube, EN 10219 S275JOH CS Cold Formed Rectangular Hollow Section Stockist in Mumbai, India.


Ranfit Metal is a well-known manufacturer, supplier, and stockiest of Cold Formed EN 10219 S275JOH Rectangular Hollow Section. The Cold Formed EN 10219 S275JOH Rectangular Hollow Section is a type of structural steel product commonly used in construction and engineering applications.

With surface treatments such as galvanizing or coating, Cold Formed EN 10219 S275JOH RHS Welded Pipes exhibit strong corrosion resistance, prolonging the lifespan of structures. They possess excellent processing capabilities, allowing for straightforward cutting, welding, and other fabrication processes. The S275JOH Cold Formed RHS has good corrosion resistance. As a low carbon steel variation, the material transfers heat very well and does not crack under welding heat.

Cold-formed EN 10219 S275JOH rectangular hollow sections are structural steel sections commonly used in construction and engineering applications. These EN 10219 Cold Formed S275J0H Welded Structural Rectangular Hollow Section offer high strength and excellent versatility for structural designs. Cold Formed EN 10219 S275J0H with specific minimum yielding strength thickness not more than 16mm at 275MPA and 27J at 0 Deg C impact energy value and H hollow section.


Cold Formed S275JOH Mild Steel Rectangular Hollow Section Exporters, EN 10219 S275JOH MS Cold Formed Rectangular Tube Stockists, BS EN 10219 S275JOH Cold Formed RHS Tubes, S275JOH CS Cold Formed Rectangular Pipes Distributors, Carbon Steel S275JOH Rectangular Hollow Section Suppliers in Mumbai, Cold Formed EN 10219 S275JOH Rectangular Box Sections, Cold Formed EN 10219 S275JOH RHS Pipe Supplier in India.


Key Standards

EN 10219: This standard specifies the technical delivery conditions for cold-formed welded structural hollow sections of non-alloy and fine-grain structural steels.

S275: Refers to a minimum yield strength of 275 MPa.

JOH: J- Ensures toughness properties at 0°C. OH-Indicates it is suitable for hollow sections.


Cold Formed EN 10219 S275JOH Rectangular Hollow Section Specifications

Standard No BS EN 10219 - Cold Formed Welded Structural Hollow Sections of Non-alloy and Fine Grain Steels
Grade S275JOH
RHS (Rectangular Hollow Sections) Sizes 10mm x 15mm / 150mmx50mm / 300mmx400mm / 600mmx550mm
Outside Diameter 21.3—457.2mm
Wall Thickness 0.5mm - 25mm
Length 6000-14000 mm
Straightness Minimum 1 : 200th of any length measured along the centre line (mill straightened condition) unless otherwise specifically arranged.
Tolerance Thickness (All sizes +/- 10%)
Surface Protection Black (Self Coloured uncoated), Varnish/Oil Coating, Pre-Galvanized, Hot Dip Galvanized
Packing In bundles, Anticorrosion heat preservation, Varnish coating, Ends can be bevelled or rectangular cut, End Capped Certification & supplementary test, Finishing & Identity Mark

EN 10219 S275JOH Rectangular Hollow Pipes and Tubing Material Equivalent

Steel grade Maximum CEV for
nominal thicknesses ≤40mm
Steel name  Steel number
S275JOH 1.0149 0,40

EN 10219 S275JOH Rectangular Hollow Section Chemical Composition

Grade Min. Yield Strength Reh(Mpa) Tensile Strength Rm (MPa) Elongation % Min. Min. Impact Energy(J)
Thk≤ 16 mm Thk>16 ≤ 40 mm Thk<3 mm Thk≥3 mm -20°C 0°C 20°C
S275J0H 275 265 430-580 410-560 20 - 27 -

EN 10219 S275JOH Rectangular Hollow Pipes & Tubes Mechanical Strength

Grade Min. Yield Strength Reh(Mpa) Tensile Strength Rm (MPa) Elongation % Min. Min. Impact Energy(J)
Thk≤ 16 mm Thk>16 ≤ 40 mm Thk<3 mm Thk≥3 mm -20°C 0°C 20°C
S275J0H 275 265 430-580 410-560 20 - 27 -

Types of EN 10219 S275JOH Hollow Section Rectangular

S275JOH EN 10219 Rectangular Hollow Section

S275JOH EN 10219 Rectangular Hollow Pipes

EN 10219 S275JOH Rectangular Hollow Tubing

S275JOH Structural Rectangular Hollow Sections

EN 10219 S275JOH Welded Rectangular Hollow Pipes

cold formed S275JOH Rectangular SHS Tube

Cold Formed EN 10219 S275JOH Rectangular Hollow Section Size Chart

Size mm kg/m Size mm kg/m
40 x 20 x 2.0 1.68 40 x 20 x 2.5 2.03
40 x 20 x 3.0 2.36 40 x 25 x 1.5 1.44
40 x 25 x 2.0 1.89 40 x 25 x 2.5 2.23
50 x 25 x 2.0 2.21 50 x 25 x 2.5 2.72
50 x 25 x 3.0 3.22 50 x 30 x 2.5 2.92
50 x 30 x 3.0 3.45 50 x 30 x 4.0 4.46
50 x 40 x 3.0 3.77 60 x 40 x 2.0 2.93
60 x 40 x 2.5 3.71 60 x 40 x 3.0 4.39
60 x 40 x 4.0 5.72 70 x 50 x 2 3.56
70 x 50 x 2.5 4.39 70 x 50 x 3.0 5.19
70 x 50 x 4.0 6.71 80 x 40 x 2.5 4.26
80 x 40 x 3.0 5.34 80 x 40 x 4.0 6.97
80 x 40 x 5.0 8.54 80 x 50 x 3.0 5.66
80 x 50 x 4.0 7.34 90 x 50 x 3.0 6.28
90 x 50 x 3.6 7.46 90 x 50 x 5.0 10.11
100 x 50 x 2.5 5.63 100 x 50 x 3.0 6.75
100 x 50 x 4.0 8.86 100 x 50 x 5.0 10.90
100 x 60 x 3.0 7.22 100 x 60 x 3.6 8.59
100 x 60 x 5.0 11.70 120 x 80 x 2.5 7.65
120 x 80 x 3.0 9.03 120 x 80 x 4.0 12.00
120 x 80 x 5.0 14.80 120 x 80 x 6.0 17.60
120 x 80 x 8.0 22.9 150 x 100 x 5.0 18.70
150 x 100 x 6.0 22.30 150 x 100 x 8.0 29.10
150 x 100 x 10.0 35.70 160 x 80 x 5.0 18.00
160 x 80 x 6.0 21.30 160 x 80 x 8.0 27.90
200 x 100 x 5.0 22.70 200 x 100 x 6.0 27.00
200 x 100 x 8.0 35.4 200 x 100 x 10.0 43.60
250 x 150 x 5.0 30.5 250 x 150 x 6.0 38.2
250 x 150 x 8.0 48.0 250 x 150 x 10 59.3
300 x 200 x 6.0 48.10 300 x 200 x 8.0 60.50
300 x 200 x 10.0 75.00 400 x 200 x 8.0 73.10
400 x 200 x 10.0 90.70 400 x 200 x 16 142.00

RHS Thickness Sec Area Unit Moment of Inertia Radius of Gyration Elastic Modulus Torsional Constants Outer
Surface Area
mm mm cm2 kg/m cm4 cm4 cm cm cm3 cm3 cm4 cm3 m2
50x25 2 2.74 2.15 8.38 2.81 1.75 1.01 3.35 2.25 6.97 3.79 0.142
2.6 3.46 2.71 10.16 3.36 1.71 0.99 4.06 2.69 8.27 4.53 0.137
3.2 4.13 3.24 11.63 3.8 1.68 0.96 4.35 3.04 9.52 5.12 0.134
4 4.95 3.88 13.13 4.23 1.63 0.92 5.25 3.38 10.86 5.69 0.129
60x40 2.26 4.76 3.73 22.76 12.09 2.19 1.59 7.59 6.05 25.59 9.83 0.187
2.9 5.25 4.12 24.74 13.11 2.17 1.58 8.25 6.56 28.02 10.66 0.185
3.6 6.35 4.98 28.9 15.23 2.13 1.55 9.63 7.62 33.3 12.41 0.181
4.5 7.67 6.02 33.31 17.44 2.08 1.51 11.1 8.72 39.34 14.29 0.177
60x33 2.6 4.7 3.69 25.15 8.43 2.31 1.34 7.62 5.11 20.75 8.71 0.185
2.9 5.19 4.07 27.33 9.12 2.29 1.33 8.28 5.53 22.65 9.43 0.183
3.6 6.28 4.93 31.87 10.52 2.25 1.29 9.66 6.37 26.71 10.9 0.179
4.5 7.58 5.95 36.64 11.93 2.20 1.25 11.1 7.23 31.21 12.43 0.175
80x40 2.6 5.8 4.55 46.58 15.74 2.84 1.65 11.65 7.87 38.5 13.46 0.227
2.9 6.41 5.03 50.87 17.11 2.82 1.63 12.72 8.56 42.23 14.66 0.225
3.2 7.01 5.5 54.94 18.41 2.8 1.62 13.74 9.21 45.83 15.78 0.224
4 8.55 6.71 64.79 21.49 2.75 1.59 16.2 10.74 54.77 18.49 0.219
4.8 10.01 7.85 73.22 24.03 2.71 1.55 18.3 12.02 62.81 20.79 0.215
96x48 3.2 8.54 6.71 98.61 33.28 3.4 1.97 20.54 13.87 82.13 23.82 0.272
4 10.47 8.22 117.54 39.32 3.35 1.94 24.49 16.38 99.11 28.24 0.267
4.8 12.31 9.66 134.35 44.55 3.3 1.9 27.99 18.56 114.8 32.14 0.263
122x61 3.6 12.32 9.67 232.61 78.83 4.34 2.53 38.13 25.85 193.91 44.5 0.347
4.5 15.14 11.88 278.94 93.78 4.29 2.49 45.73 30.75 235.39 53.13 0.343
5.4 17.85 14.01 320.83 107.03 4.24 2.45 52.6 35.09 347.29 60.89 0.338
120x60 3.2 10.85 8.51 199.88 67.95 4.29 2.5 33.31 22.65 165.83 28.95 0.344
3.6 12.11 9.5 220.75 74.77 4.27 2.48 36.79 24.92 184.1 42.91 0.341
4.5 14.87 11.67 264.52 88.88 4.22 2.44 44.09 29.63 223.34 51.19 0.337
145x82 4.8 20.28 15.92 555.16 228.50 5.23 3.36 76.57 55.73 534.27 94.45 0.429
5.4 22.6 17.74 610.85 250.59 5.2 3.33 84.26 61.12 592.7 103.81 0.426

EN 10219 S275JOH RHS Dimensional Tolerances

Dimensions less than 100mm +/- 1.0% with a minimum of +/- 0.5mm
Dimensions 100mm up to 200mm +/- 0.8%
Dimensions over 200mm +/- 0.6%
Wall thickness (excluding weld area) +/-10% for specified thickness of 5mm or below and +/-0.5mm for thickness greater than 5mm
Concavity/Convexity Max. 0.8% with a minimum of 0.5mm
Squareness of sides 90 Degree +/- 1 Degree
Externalcorner radius 6mm thick or below: 1.6 to 2.4 x wall thickness
Straightness 0.15% of total length
Twist 2mm + ( 0.5mm per mtr ) max

Cold Formed EN 10219 S275JOH SHS

Buy High Quality Cold Formed EN 10219 S275JOH Square Rectangular Section

Request the latest EN 10219 S275JOH Rectangular SHS Price List.
Please call us : +91 9987673092
mail us : sales@ranfitmetal.com
to request the updated price list and ready stock information along with your requirement.

EN 10219 S275JOH SHS Available Types

S275JOH Cold Formed CS Rectangular Hollow Section Supplier S275JOH Welded Rectangular Tubing
EN 10219 S275JOH Cold Formed Rectangular Box Sections EN 10219 S275JOH Seamless Rectangular Hollow Section Stockist
Cold Formed BS EN 10219 S275JOH Hollow Rectangular Tube, Welded Cold Formed EN 10219 S275JOH RHS Pipes
EN 10219 S275JOH Cold Formed RHS Tube Stockist EN 10219 S275JOH Rectangular Structural Steel Piping
High Temperature BS EN 10219 S275JOH Pipes EN 10219 S275JOH MS Rectangular Hollow Section Pipe
S275JOH Cold Rolled Rectangular Hollow Sections Supplier EN 10219 S275JOH Cold Formed ERW RHS Manufacturer
EN 10219 S275JOH Cold Formed Rectangular Seamless Pipe EN 10219 S275JOH Rectangular Cold Formed ERW Pipes
EN 10219 S275JOH Carbon Steel Welded RHS MAnufacturer EN 10219 Cold Formed S275JOH MS RHS Tube
EN 10219 S275JOH Seamless Cold Formed RHS Tubes EN 10219 S275JOH Rectangular Hollow Structural Sections
EN 10219 Schedule 40 S275JOH Seamless Pipes Cold formed EN 10219 S275JOH structural CFRHS

Cold Formed S275JOH SHS Manufacturing Process



EN 10219 S275JOH Cold Formed Rectangular Hollow Sections – Application Industrty

  • Petrochemical Industry
  • Aerospace Industry
  • Refineries
  • Construcion
  • Chemical Industry
  • Railway Industry
  • Oil & Gas Industry
  • Ship Building
