EN 10210 S275J2H Hot Finish Circular Hollow Section
Hot Finish EN 10210 S275J2H Circular Hollow Section
HOT FINISH EN 10210 S275J2H CIRCULAR HOLLOW SECTION MANUFACTURER & SUPPLIER IN MUMBAI, INDIA.
Hot Finish EN 10210 S275J2H Round Steel Pipe, Hot Formed EN 10210 S275J2H ERW CHS Tubing, EN 10210 S275J2H Hot Finished Circular Hollow Section Welded Tube, S275J2H MS Hot Finish Circular Section, Hot Finish EN 10210 S275J2H Round Hollow Sections, Hot Finished EN 10210 S275J2H Round Steel Tube, S275J2H Hot Finish Circular Pipe, EN 10210 S275J2H CS Hot Finish Circular Hollow Section, Hot Finish EN 10210 S275J2H Seamless Circular Hollow Section Supplier & Stockist in Mumbai, India.
Ranfit Metal is a well-known manufacturer, supplier, and stockiest of EN 10210 S275J2H Hot Finish Circular Hollow Section. Hot-finished EN 10210 S275J2H CHS are commonly used in construction, engineering, and other structural applications. S275J2H Circular Hollow Hot-finished Sections are stress-relieved, leading to better dimensional accuracy and uniformity and are suitable for dynamic loads and harsh environments. One of the main advantages The EN 10210 S275J2H HFCHS Tubing is its high strength-to-weight ratio, which makes it an ideal material for structural applications where weight reduction is critical. EN 10210 S275J2H Seamless CHS Pipes is also highly resistant to corrosion, thanks to its low carbon content and the formation of a protective oxide layer on its surface. This makes it an excellent choice for applications in harsh environments, such as coastal areas, industrial facilities, or areas with high humidity. The Finish EN 10210 S275J2H Circular hollow section used in the manufacture of machinery, equipment, and components, where its high strength, toughness, and resistance to corrosion make it an ideal material for demanding applications also in the construction of buildings, bridges, and other infrastructure projects.
S275J2H Hot Rolled Circular Tube, EN 10210 S275J2H Hot Finish Welded Circular Hollow Section, S275J2H Hot Finish CHS, EN 10210 S275J2H HF CHS, EN 10210 Hot Finish S275J2H ERW CHS Pipes Dealers in India, BS EN 10210 S275J2H Hot Finish CHS Tubes in Mumbai, Hot Finish EN 10210 S275J2H Welded Round Tube, Hot Finish EN10210 S275J2H Round Sections, EN 10210 Hot Finish S275J2H Mild Steel Circular Hollow Section Exporters, EN 10210 S275J2H Seamless Hot Finish Circular Hollow Section Tubing Exporters in Mumbai, India.
Key Standards
EN 10210: A European Standard that specifies the technical delivery conditions for Hot-Finished Structural Hollow Sections.
S235: Refers to a minimum yield strength of 235 MPa.
S235: Refers to a minimum yield strength of 235 MPa.
JRH: J: Indicates impact toughness is tested at 20°C (Charpy V-notch test). R: Represents room temperature testing. H: Stands for a Hollow SectionHot Finish EN 10210 S275J2H Circular Hollow Section Specifications
| Standard No | BS EN 10210 - Hot finished structural hollow sections of non-alloy and fine grain steels |
| Grade | S275J2H (Hot Finish) |
| CHS (Circular Hollow Sections) Sizes | 300 mm NB |
| Outer Diameter | 21.3 to 457.2mm |
| Wall Thickness | 1.8mm to 14.27mm |
| Length | 6000 to 12000/18000mm |
| Dimensional Tolerances | Thickness : (All sizes +/- 10%) |
| End Finish | mill-cut finish without further machining, Plain ended-Mechanically sheared |
| Surface Finish | Black (Self Coloured uncoated), Varnish/Oil Coating, Pre-Galvanized, Hot Dip Galvanized |
| Packing | In bundles, Anticorrosion heat preservation, Varnish coating, Ends can be bevelled or Circular cut, End Capped Certification & supplementary test, Finishing & Identity Mark |
BS EN 10210 S275J2H Circular Hollow Section Material Equivalent
| Steel Grade | Maximum CEV for nominal thicknesses ≤40mm&nb |
|
| Steel name | Steel number | |
| S275J2H | 1.0039 | 0.17 |
S275J2H EN 10210 Hot Finish Circular Hollow Section Chemical Composition
| Steel Grade | % by mass maximum | |||||||
| Steel Name | Steel Number | C specified thickness (mm) | Si | Mn | P | S | N | |
| <_40 | > 40 <_ 120 | |||||||
| S275J2H | 1.0039 | 0.17 | 0.20 | - | 1.40 | 0.040 | 0.040 | 0.009 |
Hot Finish Grade S275J2H Circular Hollow Section Mechanical Strength
| Steel Grade | Minimum yield strength eH Mpa | Minimum tensile strength Rm Mpa | ||||||||
| Steel Name | Steel Number | Specified thickness in mm | Specified thickness in mm | |||||||
| 16 | 16 _40 | 40 _63 | 63 _ 80 | 80 _100 | 100 _120 | _3 | 3_100 | 100 _ 120 | ||
| S275J2H | 1.0039 | 235 | 225 | 215 | 215 | 215 | 195 | 360-510 | 360-510 | 350-500 |
Types of EN 10219 S275J2H Hollow Section Square
Hot Finish EN 10210 S275J2H Circular Hollow Pipes
Hot Finish EN 10210 S275J2H Circular Hollow Tubing
Hot Finish EN 10210 S275J2H Structural Circular Hollow Sections
Hot Finish EN 10210 S275J2H Welded Circular Hollow Pipes
Hot Finish EN 10210 S275J2H CHS Tube
EN 10210 Hot Finish S275J2H Circular Hollow Section Size Chart
| Nominal Bore mm |
Outside diameter mm |
Thickness mm |
Weight kg/m |
|---|---|---|---|
| 15 | 21.3 | 2.00 | 0.95 |
| 2.60 | 1.21 | ||
| 3.20 | 1.44 | ||
| 20 | 26.9 | 2.30 | 1.38 |
| 2.60 | 1.56 | ||
| 3.20 | 1.87 | ||
| 25 | 33.7 | 2.60 | 1.98 |
| 3.20 | 0.24 | ||
| 4.00 | 2.93 | ||
| 32 | 42.4 | 2.60 | 2.54 |
| 3.20 | 3.01 | ||
| 4.00 | 3.79 | ||
| 40 | 48.3 | 2.90 | 3.23 |
| 3.20 | 3.56 | ||
| 4.00 | 4.37 | ||
| 50 | 60.3 | 2.90 | 4.08 |
| 3.60 | 5.03 | ||
| 5.00 | 6.19 | ||
| 65 | 76.1 | 3.20 | 5.71 |
| 3.60 | 6.42 | ||
| 4.50 | 7.93 | ||
| 80 | 88.9 | 3.20 | 6.72 |
| 4.00 | 8.36 | ||
| 4.80 | 9.90 | ||
| 100 | 114.3 | 3.60 | 9.75 |
| 4.50 | 12.20 | ||
| 5.40 | 14.50 | ||
| 125 | 139.7 | 4.50 | 15.00 |
| 4.80 | 15.90 | ||
| 5.40 | 17.90 | ||
| 150 | 165.1 | 4.50 | 17.80 |
| 4.80 | 18.90 | ||
| 5.40 | 21.30 | ||
| 150 | 168.3 | 5.00 | 20.1 |
| 6.3 | 25.2 | ||
| 8.00 | 31.6 | ||
| 10.00 | 39 | ||
| 12.5 | 48 | ||
| 200 | 219.1 | 4.80 | 25.38 |
| 6.00 | 31.51 | ||
| 8.00 | 41.67 | ||
| 10.00 | 51.59 | ||
| 250 | 273 | 6.00 | 39.51 |
| 8.00 | 52.30 | ||
| 10.00 | 64.59 | ||
| 300 | 323.9 | 6.30 | 49.36 |
| 8.00 | 62.35 | ||
| 10.00 | 77.44 |
EN 10210 Hot Finish S275J2H Circular Hollow Section Weight Chart
| Outside Diameter (mm) | Thickness (mm) | Kg/Metre |
|---|---|---|
| 21.3 | 2.5 | 1.16 |
| 21.3 | 3.2 | 1.43 |
| 26.9 | 2.5 | 1.51 |
| 26.9 | 3.2 | 1.87 |
| 33.7 | 2 | 1.56 |
| 33.7 | 2.6 | 1.99 |
| 33.7 | 3.2 | 2.41 |
| 33.7 | 4 | 2.93 |
| 42.4 | 2 | 2 |
| 42.4 | 2.6 | 2.55 |
| 42.4 | 3.2 | 3.09 |
| 42.4 | 4 | 3.79 |
| 42.4 | 5 | 4.62 |
| 42.4 | 6.3 | 5.62 |
| 48.3 | 2 | 2.29 |
| 48.3 | 2.5 | 2.83 |
| 48.3 | 3.2 | 3.56 |
| 48.3 | 4 | 4.37 |
| 48.3 | 5 | 5.34 |
| 48.3 | 6.3 | 6.53 |
| 60.3 | 2.5 | 3.57 |
| 60.3 | 3.2 | 4.51 |
| 60.3 | 4 | 5.55 |
| 60.3 | 5 | 6.82 |
| 60.3 | 6.3 | 8.4 |
| 60.3 | 8 | 10.33 |
| 60.3 | 10 | 12.42 |
| 76.1 | 2.5 | 4.54 |
| 76.1 | 3.2 | 5.75 |
| 76.1 | 4 | 7.11 |
| 76.1 | 5 | 8.77 |
| 76.1 | 6.3 | 10.86 |
| 76.1 | 8 | 13.45 |
| 76.1 | 10 | 16.32 |
| 88.9 | 3.2 | 6.76 |
| 88.9 | 4 | 8.38 |
| 88.9 | 5 | 10.3 |
| 88.9 | 6.3 | 12.85 |
| 88.9 | 8 | 15.98 |
| 88.9 | 10 | 19.48 |
| 101.6 | 2 | 4.92 |
| 101.6 | 3 | 7.3 |
| 101.6 | 4 | 9.64 |
| 101.6 | 5 | 11.93 |
| 114.3 | 3.6 | 9.83 |
| 114.3 | 4 | 10.89 |
| 114.3 | 5 | 13.5 |
| 114.3 | 6.3 | 16.8 |
| 127 | 3 | 9.17 |
| 127 | 4 | 12.15 |
| 127 | 5 | 15.04 |
| 139.7 | 3 | 10.13 |
| 139.7 | 4 | 13.4 |
| 139.7 | 5 | 16.6 |
| 139.7 | 6.3 | 20.7 |
| 139.7 | 8 | 26 |
| 139.7 | 10 | 32 |
| 168.3 | 3.6 | 14.64 |
| 168.3 | 4 | 16.23 |
| 168.3 | 5 | 20.1 |
| 168.3 | 6.3 | 25.2 |
| 168.3 | 8 | 31.6 |
| 168.3 | 10 | 39 |
| 168.3 | 12 | 46.3 |
| 193.7 | 5 | 23.3 |
| 193.7 | 6.3 | 29.1 |
| 193.7 | 8 | 36.6 |
| 193.7 | 10 | 45.3 |
| 193.7 | 12.5 | 55.9 |
| 219.1 | 5 | 26.4 |
| 219.1 | 6.3 | 33.1 |
| 219.1 | 8 | 41.6 |
| 219.1 | 10 | 51.6 |
| 219.1 | 12.5 | 63.7 |
| 244.5 | 4 | 23.73 |
| 244.5 | 5 | 29.5 |
| 244.5 | 6.3 | 37 |
| 244.5 | 8 | 46.7 |
| 244.5 | 10 | 57.8 |
| 244.5 | 12.5 | 71.5 |
| 244.5 | 16 | 90.2 |
| 273 | 5 | 33 |
| 273 | 6.3 | 41.4 |
| 273 | 8 | 52.3 |
| 273 | 10 | 64.9 |
| 273 | 12.5 | 80.3 |
| 273 | 16 | 101 |
| 323.9 | 4 | 31.6 |
| 323.9 | 5 | 39.3 |
| 323.9 | 6 | 47 |
| 323.9 | 6.3 | 49.3 |
| 323.9 | 8 | 62.3 |
| 323.9 | 10 | 77.4 |
| 323.9 | 12.5 | 96 |
| 323.9 | 16 | 121 |
| 355.6 | 8 | 68.6 |
| 355.6 | 10 | 85.2 |
| 355.6 | 12.5 | 106 |
| 355.6 | 16 | 134 |
| 406.4 | 6 | 59.2 |
| 406.4 | 8 | 78.6 |
| 406.4 | 10 | 97.8 |
| 406.4 | 12.5 | 121 |
| 406.4 | 16 | 154 |
| 457 | 6 | 66.7 |
| 457 | 8 | 88.6 |
| 457 | 10 | 110 |
| 457 | 12.5 | 137 |
| 457 | 16 | 174 |
| 508 | 6 | 74.3 |
| 508 | 8 | 98.6 |
| 508 | 10 | 123 |
| 508 | 12.5 | 153 |
| 508 | 16 | 194 |
Hot Finish EN 10210 S275J2H CHS Dimensional Tolerances
| Designation | Property | Tolerance | ||
|---|---|---|---|---|
| & | Outside Diameter D | ±1.0% with a min of ±0.5 mm and a max of ±10 mm | ||
| Thickness t | Welded | –10% | ||
| Seamless | –10% but between 10% and 12.5% may occur over not more than 25% of the circumference | |||
| Note: Positive deviation is limited by mass tolerance | ||||
| Measured at the centre of the length | Straightness (x or y direction) | 0.20% L | ||
| Mass per unit length | Mass of section | Welded | ±6.0% on individual lengths | |
| Seamless | +8.0% –6% on individual lengths | |||
| Standard | Length L | +150 mm | –0 mm | |
Buy High Quality Hot Finish EN 10210 S275J2H Circular Hollow Section
Request the latest EN 10210 S275J2H Hot Rolled CHS Price List.
Please call us : +91 9987673092
mail us : sales@ranfitmetal.com
to request the updated price list and ready stock information along with your requirement.
Hot Finish EN 10210 S275J2H CHS Available Types
| S275J2H Hot Finish CS Circular Hollow Section Supplier | S275J2H Welded Circular Tubing |
| EN 10210 S275J2H Hot Finish Circular Box Sections | EN 10210 S275J2H Seamless Circular Hollow Section Stockist |
| Hot Finish BS EN 10210 S275J2H Hollow Circular Tube, | Welded Hot Finish EN 10210 S275J2H CHS Pipes |
| EN 10210 S275J2H Hot Finish CHS Tube Stockist | EN 10210 S275J2H Circular Structural Steel Piping |
| High Temperature BS EN 10210 S275J2H Pipes | EN 10210 S275J2H MS Circular Hollow Section Pipe |
| S275J2H Hot Rolled Circular Hollow Sections Supplier | EN 10210 S275J2H Hot Finish ERW CHS Manufacturer |
| EN 10210 S275J2H Hot Finish Circular Seamless Pipe | EN 10210 S275J2H Circular Hot Finish ERW Pipes |
| EN 10210 S275J2H Carbon Steel Welded CHS MAnufacturer | EN 10210 Hot Finish S275J2H MS CHS Tube |
| EN 10210 S275J2H Seamless Hot Finish CHS Tubes | EN 10210 S275J2H Circular Hollow Structural Sections |
| EN 10210 Schedule 40 S275J2H Seamless Pipes | Hot Finish EN 10210 S275J2H Structural HFCHS |
| Hot Finish EN 10210 S275J2H Structural Hollow Sections Exporter | SCH 20 EN 10210 S275J2H Boiler Circular Seamless Pipes |
| Hot Dipped Galvanized EN 10210 S275J2H Circular Pipes | Welded Hot Finish EN 10210 S275J2H CHS Pipe |
| EN 10210 S275J2H Hot Finish MS CHS Tube | EN 10210 S275J2H Hot Finish Circular Box Sections |
| Hot Finish EN 10210 S275J2H Piping Supplier | Hot Finish EN 10210 S275J2H Tubing |
EN 10210 S275J2H Hot Finish CHS Manufacturing Process
BS EN 10210 S275J2H Hot Finish Circular Hollow Sections – Application Industrty
- Petrochemical Industry
- Aerospace Industry
- Refineries
- Construcion
- Chemical Industry
- Railway Industry
- Oil & Gas Industry
- Ship Building
