Hot Finish EN 10210 S275J2H Rectangular Hollow Section

HOT FINISH EN 10210 S275J2H RECTANGULAR HOLLOW SECTION MANUFACTURER & SUPPLIER IN MUMBAI, INDIA.

S275J2H Hot Finished CS RHS Tube, S275J2H Hot Finish Rectangular Pipe, S275J2H Hot Finish RHS, S275J2H MS Hot Finish Rectangular Section, EN 10210 S275J2H Hot Finish Welded Rectangular Hollow Section, Hot Finish EN 10210 S275J2H Seamless Rectangular Hollow Section, Hot Finish S275J2H RHS Seamless Pipes, EN 10210 S275J2H HF RHS, S275J2H Hot Rolled Rectangular Tube, EN 10210 S275J2H Hot Finished Rectangular Hollow Section Welded Tube Supplier & Stockist in Mumbai, India.

Ranfit Metal is a well-known manufacturer, supplier, and stockiest of EN 10210 S275J2H Hot Finish Rectangular Hollow Section. Hot-finished S275J2H RHS conforms to the EN 10210-1/2 standard, which governs hot-finished structural hollow sections of non-alloy and fine grain steels.

S275J2H Rectangular Hollow Hot-finished Sections Manufactured via a hot-finishing process, making them robust and ideal for applications where weldability, toughness, and dimensional accuracy are critical. The EN 10210 S275J2H HFRHS Tubing offer excellent resistance to torsion and are commonly applied in structural frameworks are used for their aesthetic appeal and mechanical properties. EN 10210 S275J2H Seamless RHS Pipes is resistant to corrosion, ensuring long-lasting durability in various environmental conditions. One of the key benefits of using S275J2H Hot Finished Rectangular Hollow Section Welded Tube is its high strength-to-weight ratio, which makes it an ideal choice for applications where weight reduction is a critical factor.

From building and architectural projects to the production of machinery and equipment, the Hot Finish EN 10210 S275J2H Rectangular Hollow Section is a type of structural steel that finds extensive use in engineering, infrastructure, and construction.

EN 10210 Hot Finish S275J2H ERW RHS Pipes Dealers in India, EN 10210 S275J2H Seamless Hot Finish Rectangular Hollow Section Tubing, S275J2H CS Hot Finished Rectangular Pipes Distributors, Hot Rolled S275J2H Mild Steel Rectangular Hollow Section Exporters, Hot Finish EN10210 S275J2H Rectangular Box Sections, BS EN 10210 S275J2H Hot Finish RHS Tubes, EN 10210 S275J2H Hot Finished Welded Structural Rectangular Hollow Sections Exporters in Mumbai, India.

Key Standards

EN 10210: A European standard that specifies the technical delivery conditions for hot-finished structural hollow sections made of non-alloy and fine-grain steels.

S235: Minimum yield strength of 235 MPa (megapascals).

JRH: J: Impact tested at 20°C. RH: Rectangular Hollow section.

Hot Finish EN 10210 S275J2H Rectangular Hollow Section Specifications

Standard No	BS EN 10210 - Hot finished structural hollow sections of non-alloy and fine grain steels
Grade	S275J2H (Hot Finish)
RHS (Rectangular Hollow Sections) Sizes	10mm x 15mm / 150mmx50mm / 300mmx400mm / 600mmx550mm
Dimensional Tolerances	Thickness (All sizes +/- 10%)
Wall Thickness	0.5mm - 25mm
Length	6000-14000 mm
Dimension Range	21.3-914mm
End Finish	mill-cut finish without further machining, Plain ended-Mechanically sheared
Surface Finish	Black (Self Coloured uncoated), Varnish/Oil Coating, Pre-Galvanized, Hot Dip Galvanized
Packing	In bundles, Anticorrosion heat preservation, Varnish coating, Ends can be bevelled or rectangular cut, End Capped Certification & supplementary test, Finishing & Identity Mark

BS EN 10210 S275J2H Rectangular Hollow Section Material Equivalent

Steel Grade		Maximum CEV for nominal thicknesses ≤40mm
Steel name	Steel number	Maximum CEV for nominal thicknesses ≤40mm
S275J2H	1.0039	0.17

S275J2H EN 10210 Hot Finish Rectangular Hollow Section Chemical Composition

Steel Grade		% by mass maximum
Steel Name	Steel Number	C specified thickness (mm)		Si	Mn	P	S	N
		_40	40 _ 120
S275J2H	1.0039	0.17	0.20	-	1.40	0.040	0.040	0.009

Hot Finish Grade S275J2H Rectangular Hollow Section Mechanical Strength

Steel Grade		Minimum yield strength eH Mpa						Minimum tensile strength Rm Mpa
Steel Name	Steel Number	Specified thickness in mm						Specified thickness in mm
Steel Name	Steel Number	_16	16 _40	40 _63	63 _ 80	80 _100	100 _120	_3	3 _100	100 _ 120
S275J2H	1.0039	235	225	215	215	215	195	360-510	360-510	350-500

Types of EN 10219 S355J2H Hollow Section Square

EN 10210 Hot Finish Gr. S275J2H Rectangular Hollow Section Size Chart

Nominal Bore mm	Outside diameter mm	Thickness mm	Weight kg/m
Size mm	kg/m	Size mm	kg/m
40 x 20 x 2.0	1.68	40 x 20 x 2.5	2.03
40 x 20 x 3.0	2.36	40 x 25 x 1.5	1.44
40 x 25 x 2.0	1.89	40 x 25 x 2.5	2.23
50 x 25 x 2.0	2.21	50 x 25 x 2.5	2.72
50 x 25 x 3.0	3.22	50 x 30 x 2.5	2.92
50 x 30 x 3.0	3.45	50 x 30 x 4.0	4.46
50 x 40 x 3.0	3.77	60 x 40 x 2.0	2.93
60 x 40 x 2.5	3.71	60 x 40 x 3.0	4.39
60 x 40 x 4.0	5.72	70 x 50 x 2	3.56
70 x 50 x 2.5	4.39	70 x 50 x 3.0	5.19
70 x 50 x 4.0	6.71	80 x 40 x 2.5	4.26
80 x 40 x 3.0	5.34	80 x 40 x 4.0	6.97
80 x 40 x 5.0	8.54	80 x 50 x 3.0	5.66
80 x 50 x 4.0	7.34	90 x 50 x 3.0	6.28
90 x 50 x 3.6	7.46	90 x 50 x 5.0	10.11
100 x 50 x 2.5	5.63	100 x 50 x 3.0	6.75
100 x 50 x 4.0	8.86	100 x 50 x 5.0	10.90
100 x 60 x 3.0	7.22	100 x 60 x 3.6	8.59
100 x 60 x 5.0	11.70	120 x 80 x 2.5	7.65
120 x 80 x 3.0	9.03	120 x 80 x 4.0	12.00
120 x 80 x 5.0	14.80	120 x 80 x 6.0	17.60
120 x 80 x 8.0	22.9	150 x 100 x 5.0	18.70
150 x 100 x 6.0	22.30	150 x 100 x 8.0	29.10
150 x 100 x 10.0	35.70	160 x 80 x 5.0	18.00
160 x 80 x 6.0	21.30	160 x 80 x 8.0	27.90
200 x 100 x 5.0	22.70	200 x 100 x 6.0	27.00
200 x 100 x 8.0	35.4	200 x 100 x 10.0	43.60
250 x 150 x 5.0	30.5	250 x 150 x 6.0	38.2
250 x 150 x 8.0	48.0	250 x 150 x 10	59.3
300 x 200 x 6.0	48.10	300 x 200 x 8.0	60.50
300 x 200 x 10.0	75.00	400 x 200 x 8.0	73.10
400 x 200 x 10.0	90.70	400 x 200 x 16	142.00

RHS	Thickness	Sec Area	Unit	Moment of Inertia		Radius of Gyration		Elastic Modulus		Torsional Constants		Outer Surface Area
mm	mm	cm2	kg/m	cm4	cm4	cm	cm	cm3	cm3	cm4	cm3	m2
50x25	2	2.74	2.15	8.38	2.81	1.75	1.01	3.35	2.25	6.97	3.79	0.142
	2.6	3.46	2.71	10.16	3.36	1.71	0.99	4.06	2.69	8.27	4.53	0.137
	3.2	4.13	3.24	11.63	3.8	1.68	0.96	4.35	3.04	9.52	5.12	0.134
	4	4.95	3.88	13.13	4.23	1.63	0.92	5.25	3.38	10.86	5.69	0.129
60x40	2.26	4.76	3.73	22.76	12.09	2.19	1.59	7.59	6.05	25.59	9.83	0.187
	2.9	5.25	4.12	24.74	13.11	2.17	1.58	8.25	6.56	28.02	10.66	0.185
	3.6	6.35	4.98	28.9	15.23	2.13	1.55	9.63	7.62	33.3	12.41	0.181
	4.5	7.67	6.02	33.31	17.44	2.08	1.51	11.1	8.72	39.34	14.29	0.177
60x33	2.6	4.7	3.69	25.15	8.43	2.31	1.34	7.62	5.11	20.75	8.71	0.185
	2.9	5.19	4.07	27.33	9.12	2.29	1.33	8.28	5.53	22.65	9.43	0.183
	3.6	6.28	4.93	31.87	10.52	2.25	1.29	9.66	6.37	26.71	10.9	0.179
	4.5	7.58	5.95	36.64	11.93	2.20	1.25	11.1	7.23	31.21	12.43	0.175
80x40	2.6	5.8	4.55	46.58	15.74	2.84	1.65	11.65	7.87	38.5	13.46	0.227
	2.9	6.41	5.03	50.87	17.11	2.82	1.63	12.72	8.56	42.23	14.66	0.225
	3.2	7.01	5.5	54.94	18.41	2.8	1.62	13.74	9.21	45.83	15.78	0.224
	4	8.55	6.71	64.79	21.49	2.75	1.59	16.2	10.74	54.77	18.49	0.219
	4.8	10.01	7.85	73.22	24.03	2.71	1.55	18.3	12.02	62.81	20.79	0.215
96x48	3.2	8.54	6.71	98.61	33.28	3.4	1.97	20.54	13.87	82.13	23.82	0.272
	4	10.47	8.22	117.54	39.32	3.35	1.94	24.49	16.38	99.11	28.24	0.267
	4.8	12.31	9.66	134.35	44.55	3.3	1.9	27.99	18.56	114.8	32.14	0.263
122x61	3.6	12.32	9.67	232.61	78.83	4.34	2.53	38.13	25.85	193.91	44.5	0.347
	4.5	15.14	11.88	278.94	93.78	4.29	2.49	45.73	30.75	235.39	53.13	0.343
	5.4	17.85	14.01	320.83	107.03	4.24	2.45	52.6	35.09	347.29	60.89	0.338
120x60	3.2	10.85	8.51	199.88	67.95	4.29	2.5	33.31	22.65	165.83	28.95	0.344
	3.6	12.11	9.5	220.75	74.77	4.27	2.48	36.79	24.92	184.1	42.91	0.341
	4.5	14.87	11.67	264.52	88.88	4.22	2.44	44.09	29.63	223.34	51.19	0.337
145x82	4.8	20.28	15.92	555.16	228.50	5.23	3.36	76.57	55.73	534.27	94.45	0.429
	5.4	22.6	17.74	610.85	250.59	5.2	3.33	84.26	61.12	592.7	103.81	0.426

Hot Finish EN 10210 S275J2H RHS Dimensional Tolerances

Characteristics	Tolerance
Outside Diameter of Size (H: Longest Side; B: Shortest Side)	H ＜ 100mm, B ＜ 100mm	max ±1% with a min of ±0.5mm
	100mm ≤ H ≤ 200mm, 100mm ≤ B ≤ 00mm	±0.8%
	H200mm, B200mm	±0.6%
Wall Thickness	WT ≤ 5mm	±10%
Wall Thickness	WT5mm	±0.5mm
Concavity/Convexity	max ±0.8% with a min of ±0.5mm
Squareness of Sides	90°±1°
External Corner Radius	WT ≤ 6mm	1.6WT ≤ R ≤ 2.4WT
	6mm ＜ WT ≤ 10mm	2.0WT ≤ R ≤ 3.0WT
	WT10mm	2.4WT ≤ R ≤ 3.6WT
Twist	2mm + 0.5mm/m in length
Straightness	1.5mm/1000mm in total length
Mass	±6% in individual lengths
Length	L＜6000mm	+5mm/-0mm
	6000mm ≤ L ≤ 10000mm	+15mm/-0mm
	L 10000mm	+5mm/-0mm plus 1mm/m

S275J2H BS EN 10210 Hot Finish RHS Tolerances on shape, Straightness & Mass

Random Length	4000 to 16000 with a range of 2000 Per order item	10% of sections supplied may be below minimum for the ordered range, but not less than 75% of the minimum of the range.
Approximate Length	4000 to 16000	500 mm
Exact Length	≥ 2000 to 6000 ≥ 6000	+10 /-0 mm +15 /-0 mm
