Ranfit Metal is a well-known manufacturer, supplier, and stockiest of Rolled Steel Flats, These flat steel products are obtained by rolling and shaping steel into flat sheets or plates, which can then be cut to specific sizes and shapes to suit different applications.

We provides rolled steel flats in grades such as S275JR and S355JR, with sizes ranging from 100mm x 10mm to 450mm x 25mm. They also offer processing services, including cutting and drilling, to cater to specific project needs. Hot-rolled steel flat bars, also known as flat stock, are ideal for the majority of processing procedures. Hot rolled steel flat bars have a rough, blue-grey finish, dull rounded edges, and irregular measurements across their length.

Rolled steel flats are a cost-effective option compared to other materials, making them an attractive choice for many industries. Rolled steel flats are made from recycled steel, making them a sustainable choice for environmentally conscious companies. Rolled steel flats are known for their versatility, durability, and strength. They are available in a range of thicknesses, widths, and lengths, making them suitable for a variety of applications.

Types of Rolled Steel Flats

• Hot-rolled steel flats: These are rolled steel flats that are produced through the hot-rolling process, which involves rolling the steel at high temperatures.
• Cold-rolled steel flats: These are rolled steel flats that are produced through the cold-rolling process, which involves rolling the steel at room temperature.
• Stainless Steel Flats: These are rolled steel flats that are made from stainless steel, which is resistant to corrosion and staining.
• Galvanized Steel Flats: These are rolled steel flats that are coated with a layer of zinc to provide corrosion resistance.

Key Features of Unequal Angles

• Unequal Leg Lengths : Both sides of the angle have the same dimension.
• 90-Degree Angle : Forms a right-angle shape, making it ideal for load-bearing applications.
• Parameters : Leg Length × Leg Length × Thickness (e.g., 50 × 50 × 5 mm)



Rolled Steel Flats Stockists in UK, Rolled Steel Flats Supplier in India, BS EN 10025-2:2004 Rolled Steel Flats Exporter, EN 10025 Grade S355JR Rolled Steel Flats Exporters & Stockist in Mumbai, India.




Standard of Rolled Steel Flats

Standard: EN 10025, EN 10058, DIN 1017-1, DIN 59200

Material: Typically mild steel (MS), Stainless steel, or high-strength steel (e.g., S275, S355).

Rolled Steel Flats Specifications

Product Name	Rolled Steel Flats
Grades	S235JR, S275JR, S355J2
Width	12mm to 300mm
Thickness (mm)	3mm to 12mm
Material	Hot-rolled, galvanized, or as specified by customer
Processing	Cut-to-length, Punching, Slotting, Stamping, Shearing
Finish	Galvanized, epoxy, and powder-coated
Application	Building Construction, Infrastructure Projects, Offshore Platforms, Stadiums and Public Areas, Parking Structures, Architectural Features, Renovation and Reinforcement




Types of EN 10219 S355J2H Hollow Section Square



S355JR, S355JO, S355J2, S275JR Rolled Steel Flats



S355JR, S355JO, S355J2, S275JR Rolled Steel Flats

Rolled Steel Flats Chemical Composition

Element	C	Cu	Fe	Mn	P	S
Percentage	0.26	0.2	99	0.75	0.04 max	0.05 max





Rolled Steel Flats Mechanical Properties

	Imperial	Metric
Density	0.282 lb/in3	7.8 g/cc
Ultimate Tensile Strength	58,000psi	400 MPa
Yield Tensile Strength	47,700psi	315 MPa
Shear Strength	43,500psi	300 MPa
Melting Point	2,590 - 2,670°F	1,420 - 1,460°C
Hardness Brinell	140
Production Method	Hot Rolled

Rolled Steel Flats Dimensions, Properties & Size Chart

Size	Kg/m	Size	Kg/m	Size	Kg/m
100 x 10 mm	7.850	200 x 10 mm	15.700	350 x 10 mm	27.470
100 x 12 mm	9.420	200 x 12 mm	18.840	350 x 12 mm	33.010
100 x 15 mm	11.775	200 x 15 mm	23.550	350 x 15 mm	41.213
100 x 20 mm	15.700	200 x 20 mm	31.400	350 x 20 mm	54.950
100 x 25 mm	19.625	200 x 25 mm	39.250	350 x 25 mm	68.680
150 x 10 mm	11.775	250 x 10 mm	19.625	400 x 10 mm	31.400
150 x 12 mm	14.130	250 x 12 mm	23.550	400 x 12 mm	37.680
150 x 15 mm	17.663	250 x 15 mm	29.438	400 x 15 mm	47.100
150 x 20 mm	23.550	250 x 20 mm	39.250	400 x 20 mm	62.800
150 x 25 mm	29.438	250 x 25 mm	49.060	400 x 25 mm	78.503
180 x 10 mm	14.130	300 x 10 mm	23.550	450 x 10 mm	35.330
180 x 12 mm	16.956	300 x 12 mm	28.260	450 x 12 mm	42.390
180 x 15 mm	21.195	300 x 15 mm	35.325	450 x 15 mm	52.980
180 x 20 mm	28.260	300 x 20 mm	47.100	450 x 20 mm	70.650
180 x 25 mm	35.325	300 x 25 mm	58.875	450 x 25 mm	88.310

Rolled Steel Flats Weight Chart

Width W	Thicknesst, mm
	3	4	5	6	8	10	12	15	20	25	30	40	50	60
mm	Weight kg/m
10	0,27	0,31	0,393	0,47	0,63
12	0,28	0,38	0,471	0,565	0,75	0,94
14	0,33	0,44	0,55	0,66	0,88	1,10	1,32
15	0,35	0,47	0,589	0,707	0,942	1,18	1,41
16	0,38	0,50	0,628	0,754	1,00	1,26	1,51
18	0,42	0,57	0,71	0,85	1,13	1,41	1,70	2,12
20	0,47	0,628	0,785	0,942	1,26	1,57	1,88	2,36
25	0,60	0,785	0,981	1,18	1,57	1,96	2,36	2,94	3,93
30	0,71	0,94	1,18	1,41	1,88	2,36	2,83	3,53	4,71	5,89
35	0,84	1,10	1,37	1,65	2,20	2,75	3,30	4,12	5,50	8,24
40	0,94	1,26	1,57	1,88	2,51	3,14	3,77	4,71	6,28	7,85	9,42
45	1,06	1,41	1,77	2,12	2,83	3,53	4,24	5,30	7,07	8,83	10,60	14,13
50	1,18	1,57	1,96	2,36	3,14	3,93	4,71	5,89	7,85	9,81	11,8	15,70
55	1,30	1,73	2,16	2,59	3,45	4,32	5,18	6,48	8,64	10,08	12,95	17,27
60	1,41	1,88	2,36	2,83	3,77	4,71	5,65	7,07	9,42	11,8	14,1	18,8	23,60
65	1,53	2,04	2,55	3,06	4,08	5,10	6,12	7,65	10,21	12,76	15,31	20,41	25,51
70	1,65	2,20	2,75	3,30	4,40	5,50	6,59	8,24	11,0	13,7	16,5	22,0	27,5
75	1,77	2,36	2,94	3,53	4,71	5,89	7,06	8,83	11,80	14,72	17,66	23,55	29,40
80	1,88	2,51	3,14	3,77	5,02	6,28	7,54	9,42	12,6	15,7	18,8	25,1	31,4	37,7
90	2,12	2,83	3,53	4,24	5,65	7,07	8,48	10,6	14,1	17,7	21,2	28,3	35,3	42,4
100	2,36	3,14	3,93	4,71	6,28	7,85	9,42	11,8	15,7	19,6	23,6	31,4	39,3	47,1
110	2,59	3,45	4,32	5,18	6,91	8,64	10,36	12,95	17,27	21,59	25,91	34,54	43,20	51,81
120	2,83	3,77	4,71	5,65	7,54	9,42	11,3	14,1	18,8	23,6	28,3	37,7	47,1	56,5
130	3,06	4,08	5,10	6,12	8,16	10,21	12,25	15,31	20,41	25,51	30,62	40,82	51,00	61,23
140	3,30	4,40	5,50	6,59	8,79	11,00	13,19	16,49	21,98	27,48	32,97	43,96	55,00	65,94
150	3,53	4,71	5,80	7,06	9,42	11,8	14,1	17,7	23,6	29,4	35,3	47,1	58,9	70,7
160	3,77	5,02	6,28	7,54	10,05	12,56	15,07	18,84	25,12	31,40	37,68	50,24	62,80	75,36
170	4,00	5,34	6,67	8,01	10,68	13,35	16,01	20,02	26,69	33,40	40,00	53,40	66,73	80,07
180	4,24	5,65	7,06	8,48	11,30	14,13	16,96	21,20	28,26	35,33	42,39	56,50	70,65	84,78
200	4,71	6,28	7,85	9,42	12,56	15,70	18,84	23,55	31,40	39,20	47,10	62,80	78,50	94,20





Dimensional Tolerances Rolled Steel Flats

Width (W) mm				Thickness (T) mm
Tolerance band			Tol ± (mm)	Tolerance band			Tol ± (mm)
10	–	40	0.75	3	–	20	0.5
40	–	80	1.00	20	–	40	1.0
80	–	100	1.50	40	–	80	1.5
100	–	120	2.00
120	–	150	2.50




Bar Length (L) m			Tol (mm)
6	–	12	+300 -0
