Ranfit Metal is a well-known manufacturer, supplier, and stockiest of Gr. S235JR Structural Steel Plates. S235JR is a non-alloy structural steel grade defined by EN 10025-2. It is frequently utilized in construction and engineering due to its high weldability, toughness, and strength.

S235JR steel plates are perfect for structural applications because of their high strength and low weight. S235JR steel plates are appropriate for a variety of applications because they are simple to weld using a variety of welding processes. Because of its strong resistance to corrosion, Gr. S235JR Structural Steel Plates can be used in challenging conditions. Comparing S235JR steel plates to other structural steel grades, they are a more affordable choice.

The "S" in S235JR stands for "structural steel," while 235 refers to the minimum yield strength of 235 MPa. The "JR" designation indicates that the steel has undergone a Charpy impact test at 27J at room temperature (20°C).

The Structural Steel Gr. S235JR Plates are made from high-grade raw materials to assure international raw material quality. Customers can choose between numerous forms, thicknesses, and shapes for their plates. The business produces high-quality plates thanks to a highly experienced group of qualified professionals and the effective application of cutting-edge technology and machinery.

Key Features of S235JR Specification

Equivalent Grades: ASTM A36 / DIN ST37-2 / JIS SS400 / EN 10025-2 S235JR

International Standards: EN 10025-2 / ASTM A36 / DIN EN 10025-2 / JIS G3101

Gr. S235JR Structural Steel Plates Specifications

Gr. S235JR Structural Steel Plates Equivalent Grades

EN	DIN,WNr	JIS	AFNOR	IS	ISO	UNI	ASTM
S235JR	RSt37-2 RSt37-2	SM400A SS400	E24	IS226	E235B Fe360B	FE360B	A283 C

S235JR Structural Steel Plates Chemical Composition

<

Carbon (C)	0.17 – 0.20%
Manganese (Mn)	1.40%
Phosphorus (P)	0.035%
Sulfur (S)	0.035%
Silicon (Si)	0.55%
Copper (Cu)	0.55%

Structural Steel Gr. S235JR Plates Mechanical Properties

Property	Value
Yield Strength (MPa)	235 (for thickness ≤16mm)
Tensile Strength (MPa)	360 – 510
Elongation (%)	17 – 20%
Impact Test (Charpy V-Notch)	27J @ 20°C

Structural Steel Gr. S235JR Plates Physical Properties

Property	Value
Density	7.85 g/cm³
Melting Point	1420-1460°C
Specific Heat Capacity	500 J/kg°C
Thermal Conductivity	50 W/mK

Types of EN 10219 S355J2H Hollow Section Square

Structural Steel Grade S235JR Analogues

S235JR Steel Plate Weight Chart

Are you trying to find reliable S235JR Structural Plates manufacturers?

You're in the proper location!
Please call us : +91 9987673092
mail us : sales@ranfitmetal.com
to request the updated price list and ready stock information along with your requirement.

Structural Steel S235JRH Available Types

S235JR Structural Steel Plates Manufacturing Process

S235JR Structural Steel Plates – Application Industrty
