Gr. S355J2W Steel Plates
GR. S355J2W WEATHERING STEEL PLATES MANUFACTURER & SUPPLIER IN MUMBAI, INDIA.
GR. S355J2W WEATHERING STEEL PLATES MANUFACTURER & SUPPLIER IN MUMBAI, INDIA.
ASTM A242 Corten S355J2W Plate, S355J2W High-Strength Low-alloy Structural Steel Plates, S355J2W Corten Equivalent Plates Stockist, Corten Steel S355J2W Plates, S355J2W Steel Plates Stockist, S355J2W Corten Steel Plates Distributor, A588 Corten Plates Exporter, S355J2W Plates, S355J2W Corten Steel Plates in Mumbai, India.
Ranfit Metal is a well-known manufacturer, supplier, and stockiest of Gr. S355J2W weathering steel plates. Gr. S355J2W is a weathering steel grade under the EN 10025-5 standard. S355J2W Plates are a type of high-strength, low-alloy (HSLA) steel that exhibits exceptional corrosion resistance and durability in harsh environmental conditions.
The grade S355J2W Corten Resistant Steel Plates has been optimized for improved atmospheric corrosion resistance, making it an ideal choice for outdoor applications where exposure to the elements is a concern. The Gr. S355J2W Corten Equivalent Plates has ability to withstand harsh environmental conditions without the need for additional coatings or treatments reduces its environmental impact. Gr. S355J2W Weather Resistant Plates are used in a variety of applications where their unique combination of strength, corrosion resistance such as Bridges and structural components, Industrial chimneys and towers, Power plant Structures, Railway wagons, Shipping containers, Architectural cladding and sculptures more
The "S" stands for structural steel, "355" represents the minimum yield strength (355 MPa), and "JOW" indicates improved resistance to atmospheric corrosion due to added alloying elements like copper, nickel, and phosphorus.
The production process of Gr. S355J2W Weathering Steel Plates involves several stages, including: Steelmaking, Casting, Rolling, Heat treatment, Testing and inspection etc. Gr. S355J2W weathering steel plates can be fabricated and welded using conventional techniques, including cutting, drilling, grinding, and welding.
EN10025-5 S355J0W Corten Steel Plates, ASTM A242 S355J2W High-Strength Low-alloy Structural Plate, A242 S355J2W Weather Resistant Plates, S355J2W Corten Plates, Corten Equivalent Steel S355J2W Hot Rolled Plates, A588 Corten S355J2W Plates, Corten Steel S355J2W Corrosion Resistant Steel Plates, S355J2W Weathering Structural Plates, S355J2W Weathering Steel Plates Supplier Stockist in Mumbai, India.
Key Features of Gr. S355J2W Specification
Steel Number: 1.8959
International Standards: EN 10025-5:2004 / ASTM A242 / AS/NZS 3678 / JIS / EN 10025-2
Gr. S355J2W Weathering Steel Plates Specifications
| Standard | EN 10025-5 / ASTM A588, A242 / ASME SA588, SA242 |
| Grade | S355J0W, S355J0W+N |
| Type | Weathering Steel / Weather Resistant / Corten Steel / High-Strength Low-alloy Structural Steel |
| Thickness | 5 mm - 150 mm |
| Width | 1000 mm - 4500 mm |
| Length | 3000 mm - 18000 mm, or cut shapes as required or as custom’s request |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR) |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
Gr. S355J2W Weathering Steel Plates Equivalent Grades
| EN 10025-2 | Steel Number | DIN, WNr | USX CORP (proprietary) | European old EN | JIS | BS | AFNOR |
|---|---|---|---|---|---|---|---|
| S355J2W | 1.8965 | WTSt 52-3 | COR-TEN B ® | S355J2G2W | SMA50CP | WR50C | E36 WB 4 |
S355J2W Weathering Steel Plates Chemical Composition
| Grade | C | Si | Mn | P | S | N | Cr | Cu |
|---|---|---|---|---|---|---|---|---|
| S355J0W | 0.16 | 0.50 | 0.50/1.50 | 0.035 | 0.035 | 0.009 | 0.40/0.80 | 0.25/0.55 |
Corten Equivalent Gr. S355J2W Steel Plates Mechanical Properties
| Grade | Min. Yield Strength Reh MPa | Tensile Strength Rm MPa | |||||||
|---|---|---|---|---|---|---|---|---|---|
| Nominal Thickness (mm) | Nominal Thickness (mm) | ||||||||
| ≤16 | 16 ≤40 | 40 ≤63 | 63 ≤80 | 80 ≤100 | 100 ≤150 | 3 | 3 ≤100 | 100 ≤150 | |
| S355J0W | 355 | 345 | 335 | 325 | 315 | 295 | 510/680 | 470/630 | 450/600 |
Types of Gr. S355J2W Hollow Section Square
Grade S355J2W Weathering Steel Plates
EN 10025-5 S355J2W Corten Equivalent Steel Plates
Structural Steel Grade ST523 Analogues
| US | 1015 |
| Germany | RSt37-2, USt37-2, St37-2 |
| France | E24-2 |
| UK | 40B |
| Spain | AE 235 B-FN, AE 235 B-FU |
| Italy | Fe360B |
| Belgium | AE 235-B |
| Sweden | 1311, 1312 |
| Portugal | Fe360-B |
| India | IS226 |
| Austria | RSt360B, USt360B |
| Japan | SM400A, SS400 |
| China | Q235A, Q235B, Q235D |
| Russia | Ст2пс, Ст2сп, Ст3пс, Ст3сп |
ST523 Steel Plate Weight Chart
| Dimensions (mm) | Weight (Kg /m2) |
|---|---|
| 2000 x 1000 x 3 mm | 26.019 Kg /m2 |
| 2500 x 1250 x 3 mm | 26.019 Kg /m2 |
| 2000 x 1000 x 4.05 mm | 37.097 Kg /m2 |
| 2500 x 1250 x 4.05 mm | 37.097 Kg /m2 |
| 3000 x 1500 x 4.05 mm | 37.097 Kg /m2 |
| 4000 x 1750 x 4.05 mm | 37.097 Kg /m2 |
| 2500 x 1250 x 6 mm | 48.070 Kg /m2 |
| 4000 x 1750 x 6 | 48.070 Kg /m2 |
| 2000 x 1000 x 6 | 48.070 Kg /m2 |
| 2000 x 1000 x 8 | 65.044 Kg /m2 |
| 3000 x 1500 x 6 | 48.070 Kg /m2 |
| 4000 x 1750 x 12.05 | 100.077 Kg /m2 |
| 2500 x 1250 x 8 | 65.044 Kg /m2 |
| 4000 x 1750 x 8 | 65.044 Kg /m2 |
| 4000 x 1830 x 6 | 48.070 Kg /m2 |
| 2000 x 1000 x 10 | 81.014 Kg /m2 |
| 3000 x 1500 x 10 | 81.014 Kg /m2 |
| 3000 x 1500 x 8 | 65.044 Kg /m2 |
| 6000 x 1750 x 12.05 | 100.077 Kg /m2 |
| 2500 x 1250 x 10 | 81.014 Kg /m2 |
| 4000 x 1750 x 10 | 81.014 Kg /m2 |
| 2000 x 1000 x 12.05 | 100.077 Kg /m2 |
| 3000 x 1500 x 12.05 | 100.077 Kg /m2 |
| 6000 x 1830 x 10 | 81.014 Kg /m2 |
| 2500 x 1250 x 12.05 | 100.077 Kg /m2 |
Are you trying to find reliable S355J2W Weathering Steel / Corten Equivalent Plates manufacturers?
You're in the proper location!
Please call us : +91 9987673092
mail us : sales@ranfitmetal.com
to request the updated price list and ready stock information along with your requirement.
Steel Plate S355J2W RHS Available Types
| Hot Finish S355J2W Plate | Grade S355J2W Carbon Steel Plate |
| Square S355J2W Pipe Manufacturers in India | Structural Steel S355J2W Plate price |
| High Strength Structural Steel S355J2W Plates | S355J2W Plates Stockist in Mumbai |
| Carbon Steel S355J2W Sheet Plate Suppliers in Mumbai | Structural Steel S355J2W Plate Supplier & Stockist in India |
| S355J2W High Tensile Steel Plate | DIN S355J2W Plates Stockist |
| Structural S355J2W half plate Exporter | S355J2W Large Diameter Plates Trader |
| S355J2W Structural Sheet in india | Inconel Black sheet Exporter |
| S355J2W sheet price per kg at Best Price | high tensile S355J2W Structural steel plate |
| JIS S355J2W Mild Steel Plate | S355J2W Hot Rolled Structural Steel Plate |
| Gr. S355J2W Structural Steel Plates | S355J2W Plates Dealer in India |
S355J2W Structural Steel Plates Manufacturing Process
S355J2W Weathering Steel / Corten Equivalent Plates – Application Industrty
- Petrochemical Industry
- Aerospace Industry
- Refineries
- Construcion
- Chemical Industry
- Railway Industry
- Oil & Gas Industry
- Ship Building
