Ranfit Metal is a well-known manufacturer, supplier, and stockiest of HEB (IPB) European Wide Flange Beams, The term "HEB" refers to the specific type of structural beam defined by European standards (EN 10365), which is characterized by its wide flange and the "I" shape, offering good strength and stability.

HEB beams are characterized by their wide flange and web shape, which provides excellent structural integrity and resistance to bending, compression, and torsion. They are made from high-strength steel, typically with a yield strength of 235-355 MPa, and are available in a range of sizes and lengths to suit specific project requirements. The fabrication process involves cutting, drilling, and welding the steel to create the desired shape and size. HEB beams can be fabricated in a variety of finishes, including hot-dipped galvanized, painted, or coated with a corrosion-resistant material.

The dimensions of HEB beams are standardized according to European standards (EN 10024:1994), with the most common sizes ranging from HEB 100 to HEB 1000. The width of the flange ranges from 100 mm to 1000 mm, and the thickness of the web ranges from 5 mm to 40 mm.

HEB beams are used as columns, beams, and roof supports in commercial and residential buildings, providing strength and stability to the structure. HEB beams are used in the construction of industrial facilities, such as factories, warehouses, and power plants, providing a robust and durable structure.

Advantages of HEB Beams

• High strength-to-weight ratio: HEB beams provide excellent strength and stability while minimizing the weight of the structure, making them ideal for large and complex projects.
• Versatility: HEB beams are available in a range of sizes and lengths, making them suitable for a wide range of applications and project requirements.
• Cost-effectiveness: HEB beams are a cost-effective solution for construction and engineering projects, providing a strong and durable structure at a competitive price.
• Durability: HEB beams are made from high-strength steel, which provides excellent resistance to corrosion and wear, ensuring a long lifespan and minimal maintenance requirements.

Key Features of HEA (IPBL) Beams

Shape: The cross-section of an HEB beam is I-shaped, with horizontal flanges and a vertical web, providing strength against bending.

Standardization: HEB beams come in various sizes, with standard dimensions such as height (h), flange width (b), and web thickness (t).

Material: Typically made from structural steel, offering high tensile strength and durability.

HEB (IPB)- European Wide Flange Beams Specifications

HEB (IPB) Beams Grades Material Equivalent

EU	US
S235	A283C/ EN 1.0038
S275	A570Gr40 / EN 1.0044
S355	A572Gr50 / EN 1.0045 / EN 1.0577

HEB (IPB) Beams Grades Chemical Composition

Grade	C%	Mn%	P%	S%	Si%
S235	0.22 max	1.60 max	0.05 max	0.05 max	0.05 max
S275	0.25 max	1.60 max	0.04 max	0.05 max	0.05 max
S355	0.23 max	1.60 max	0.05 max	0.05 max	0.05 max

HEB (IPB) Beams Grades Mechanical Properties

Structural Steel Grade at 16mm	Minimum Yield Strength at nominal thickness 16mm
	psi	N/mm2 (MPa)
S235	33 000	235 N/mm2
S275	36 000	275 N/mm2
S355	50 000	355 N/mm2

Types of HEB (IPB) Beams Grades Hollow Section Square

HEA Beams Size Chart

HEA Beam Section Area

Buy High Quality HEB Beam

Buy High Quality HEB Beam

Request the latest HEB Profile Price List.
Please call us : +91 9987673092
mail us : sales@ranfitmetal.com
to request the updated price list and ready stock information along with your requirement.

HEB Profile Steel Available Types

DIN Profile – Application Industrty
